Front components
Item Component Function
(1) Camera light (select models only) On: The camera is recording or streaming video or
capturing a still photograph.
(2) Camera mode switch
●
To use macro mode, slide the switch to the left. Macro
mode uses a focal length of approximately 10 cm for
capturing close-up images.
●
To use normal mode, slide the switch to the right.
Normal mode uses a focal length of approximately 50
cm for capturing images within a standard range of
distance from the camera.
(3) Keyboard light button Opens and turns on the keyboard light.
(4) External WWAN antenna button Opens the external WWAN antenna.
(5) External WWAN antenna Sends and receives wireless signals to communicate with
a WWAN.
(6) Power switch
●
When the computer is off, slide the switch to the right
to turn on the computer.
●
When the computer is on, slide the switch to the right
to shut down the computer.
●
When the computer is in the Sleep state (Windows
Vista) or in Standby (Windows XP), slide the switch to
the right briefly to exit Sleep or Standby.
●
When the computer is in Hibernation, slide the switch
to the right briefly to exit Hibernation.
If the computer has stopped responding and Windows®
shutdown procedures are ineffective, slide the switch to the
right and hold for at least 5 seconds to turn off the computer.
To learn more about your power settings, follow these
steps:
●
In Windows Vista, select Start > Control Panel >
System and Maintenance > Power Options.
●
In Windows XP, select Start > Control Panel >
Performance and Maintenance > Power Options.
(7) Display release latch Opens the computer.
(8) Bluetooth® compartment Contains an optional Bluetooth device.
Front components 11
