Battery
Description Spare part number
6-cell, 4.4-Wh battery 454668-001
6-cell, 2.0-Wh battery (for Thailand only) 464482-001
Ultra-slim extended life battery 443157-001
Before disassembling the computer, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
Remove the battery:
1. Turn the computer upside down on a flat surface, with the battery bay toward you.
2. Slide the battery release latch (1) to release the battery.
3. Pivot the battery upward (2) and remove it from the computer (3).
Install the battery by inserting it into the battery bay until you hear a click.
Component replacement procedures 39
