ENWW TCP/IP Configuration 23
configuration file can be downloaded using TFTP. This TFTP
configuration file’s relative path name is specified in the BOOTP
reply using the /etc/bootptab file’s T144 vendor-specific tag
entry. An example of a TFTP configuration file is provided below
(the symbol ‘#’ denotes a remark and is not included in the file).
#
# Example of an HP Jetdirect TFTP Configuration File
#
# Allow only Subnet 192.168.10 access to peripheral.
# Up to four ‘allow’ entries can be written via TFTP.
# Up to 10 ‘allow’ entries can be written via SNMP.
# ‘allow’ may include single IP addresses.
#
allow: 192.168.10 255.255.255.0
#
#
# Disable Telnet
#
telnet: 0
#
# Enable the embedded web server
#
ews-config: 1
#
# Detect SNMP unauthorized usage
#
authentication-trap: on
#
# Send Traps to 192.168.10.1
#
trap-dest: 192.168.10.1
#
# Specify the Set Community Name
#
set-community-name: 1homer2
#
# End of file
