Common hardware
227
Table 30. Internal components (1 of 3)
Reference Part number Description
RG5-3484-070CN Paper pickup assembly
RG5-3486-040CN Pickup roller assembly
RG5-3474-020CN Delivery assembly
1 RB2-3345-000CN Cap
2 RB1-7247-000CN Paper guide
3 RB2-3350-000CN Cable guide, formatter
4 RF5-2664-000CN Reinforcement plate
5 RB2-3364-000CN Metal plate
6 RB1-7130-020CN Cable guide
7 RB1-7234-000CN Cap
8 RB2-3366-000CN Cable guide holder, formatter
9 XA9-0724-000CN Screw M3X8 (11)
10 XA9-0855-000CN Screw, RS, with washer, M3X8
11 RB1-7176-000CN Guide sheet
12 RB2-4118-000CN Grounding plate
13 RB2-3467-000CN Grounding plate (2)
14 WT2-5178-000CN Cable guide, control panel
15 WT2-5300-000CN Cable guide, frame
16 XA9-0779-000CN Screw
17 RB2-3465-000CN Left hinge holder
18 RB2-3466-000CN Right hinge holder
19 XA9-0434-000CN Screw, TP, M3X4 (4)
20 RG5-4237-000CN Cable, grounding, document scanner motor
21 XA9-0267-000CN Screw
22 C3949-60001 Formatter—LJ 3100
C3949-69001 Formatter—LJ 3100 (exchange)
C3949-60002 Formatter—LJ 3150
C3949-69002 Formatter—LJ 3150 (exchange)
23 C3948-00002 RFI shield
24 C3948-60001 LIU board (U.S.)
24 C3948-60002 LIU board (worldwide)
25 0515-2672 Screw, M3X6 (9)
501 XB4-7400-807CN Screw, tapping, truss head, M4X8 (3)
