Table 32. Internal components (3 of 3)
Reference Part number Description
RG5-3475-040CN Separation guide assembly
1 RB1-7223-000CN Grounding clip
2 RB1-7246-000CN Bushing (2)
3 RB1-7341-030CN Right cartridge guide #1
4 RF5-2364-000CN Pressure roller
5 RF5-1517-020CN Pressure plate
6 RF5-2358-000CN Transfer guide
7 RF5-1534-000CN Transfer roller
8 RB1-7129-000CN Grounding metal
9 RF5-1515-020CN Right cartridge guide #2
10 RF5-1514-020CN Left cartridge guide
11 RS5-0796-000CN Pressure roller gear (27T)
12 RB1-7256-000CN Right side plate
13 RB1-7255-000CN Left side plate
14 RF5-1533-000CN Pressure roller ground guide
15 VS1-5057-002CN Fuser connector (2P)
16 RG5-4678-000CN Fixing assembly, 110 V
16 RG5-4681-000CN Fixing assembly, 220 V
17 XA9-0724-000CN Screw, M3X8
18 XA9-0686-000CN Screw, M3X6
19 RS5-2508-000CN Spring, compression
20 XA9-0824-000CN Screw, RS, M3X10
21 RG5-3452-000CN Transfer guide assembly
CK-8006-000CN Pressure roller grease
