EN
Numerical parts list
251
RB2-3346-000CN Speaker mount 95 1
RB2-3347-000CN Spacer, PCB (7) 95 3
RB2-3350-000CN Cable guide, formatter 92 3
RB2-3351-000CN Cable tube 89 13
RB2-3354-000CN Strap 89 1
RB2-3360-000CN Left cover 88 3
RB2-3361-000CN Rear cover 88 4
RB2-3362-000CN Paper input support 87 1
RB2-3364-000CN Metal plate 92 5
RB2-3365-000CN Sheet, arching (2) 90 1
RB2-3366-000CN Cable guide holder, formatter 92 8
RB2-3393-000CN One-touch pad overlay sheet 87 6
RB2-3401-000CN Duct, 1 90 4
RB2-3402-000CN Duct, 2 90 5
RB2-3409-000CN Cable guide 89 19
RB2-3410-000CN Paper output support 87 2
RB2-3436-000CN Document scanner guide 89 5
RB2-3448-000CN Paper path lever—LJ 3150 (darker in color) 88 12
RB2-3449-000CN Front casing 88 6
RB2-3450-000CN Top cover 88 7
RB2-3451-000CN Left front cover 88 8
RB2-3452-000CN Pressure release lever cover 88 11
RB2-3453-000CN Paper path lever—LJ 3100 (lighter in color) 88 12
RB2-3454-000CN Spacer 89 15
RB2-3455-000CN Document feeder support 87 3
RB2-3465-000CN Left hinge holder 92 17
RB2-3466-000CN Right hinge holder 92 18
RB2-3467-000CN Grounding plate (2) 92 13
RB2-3468-000CN Left hinge cover 89 17
RB2-3469-000CN Right hinge cover 89 18
RB2-3470-000CN Document output support 87 4
RB2-4118-000CN Grounding plate 92 12
Table 39. Numerical parts list
Part number Part name Figure # Reference
