252 Parts and diagrams
EN
RB9-0227-000CN Spacer 93 24
RF5-1514-020CN Left cartridge guide 94 10
RF5-1515-020CN Right cartridge guide #2 94 9
RF5-1517-020CN Pressure plate 94 5
RF5-1533-000CN Pressure roller ground guide 94 14
RF5-1534-000CN Transfer roller 94 7
RF5-2358-000CN Transfer guide 94 6
RF5-2364-000CN Pressure roller 94 4
RF5-2367-000CN Exit roller 93 17
RF5-2368-000CN Fuser exit roller assembly 98 7
RF5-2372-000CN Plate, middle 96 18
RF5-2663-000CN Foot (4) 95 4
RF5-2664-000CN Reinforcement plate 92 4
RG5-1947-000CN Paper feed drive assembly 96 9
RG5-2029-000CN Cable, paper pickup 95 8
RG5-2032-000CN Cable, thermistor 95 10
RG5-2033-000CN Cable, motor 95 11
RG5-2035-000CN Cable, laser 95 5
RG5-3452-000CN Transfer guide assembly 94 21
RG5-3453-000CN Switch lever assembly 93 16
RG5-3474-020CN Delivery assembly 92, 99
RG5-3475-040CN Separation guide assembly 94, 98
RG5-3476-000CN Face-up/face-down lever 98 2
RG5-3478-000CN Spur assembly inside (2) 99 7
RG5-3479-000CN Spur assembly outside (2) 99 6
RG5-3484-070CN Paper pickup assembly 92, 96
RG5-3485-030CN Feed assembly 96, 97
RG5-3486-040CN Pickup roller assembly 92, 96
RG5-3488-000CN Input bin assembly 88 9
RG5-3497-050CN Laser/scanner assembly 93 19
RG5-3661-000CN Cable, scanner 95 12
RG5-3662-000CN Cable, door switch 95 9
Table 39. Numerical parts list
Part number Part name Figure # Reference
