Numerical parts list
253
RG5-4220-000CN Printer door assembly—LJ 3100 89, 90
RG5-4221-000CN Upper guide assembly—LJ 3100 89
RG5-4233-000CN Cable, contact image sensor (J1004 to
J903)
89 21
RG5-4237-000CN Cable, grounding, document scanner motor 92 20
RG5-4238-000CN Cable, CIS grounding 89 22
RG5-4239-000CN Contact image sensor assembly 89 11
RG5-4241-000CN Control panel assembly—LJ 3100 89
RG5-4678-000CN Fixing assembly, 110 V 94 16
RG5-4681-000CN Fixing assembly, 220 V 94 16
RG5-4690-000CN ECU, 110 V 95 18
RG5-4691-070CN ECU, 220 V 95 18
RG5-4763-000CN Single-sheet input slot assembly 88 10
RG5-4768-000CN Upper guide assembly 89
RG5-4769-000CN Control panel assembly—LJ 3150 89
RG5-4770-000CN Printer door assembly—LJ 3150 89, 90
RG5-4771-000CN Document scanner assembly 89, 91
RG5-4772-000CN Pickup roller assembly, document scanner 91 1
RH2-5346-000CN Cable, formatter 95 6
RH6-3845-000CN Speaker 95 7
RH7-1320-000CN Motor, DC 12V 93 7
RH7-1376-000CN Motor, AC 1.08W 91 19
RH7-5139-000CN Solenoid 96 13
RS5-0796-000CN Pressure roller gear (27T) 94 11
RS5-2501-000CN Spring, compression 96 14
RS5-2508-000CN Spring, compression 94 19
RY7-5005-000CN Gear kit #1 93 1
RY7-5007-000CN Fuser release kit 93 6
RY7-5008-000CN Separation pad kit 96 2
RY7-5009-000CN Input sensor assembly 96 3
RY7-5036-000CN Gear kit #2 93 8
RY7-5055-000CN Separation pad kit for document scanner
path
89 10
Table 39. Numerical parts list
Part number Part name Figure # Reference
