94 Removal and replacement
EN
RFI shield
1 Remove all covers.
2 Remove four (4) screws (callout 1) from the RFI shield.
CAUTION When step 3 below is performed, all memory is cleared from the
formatter, including country-specific settings. Clearing memory can
render the product illegal or inoperable. See the section in Chapter 6,
“Troubleshooting,” about softswitches to restore the country code.
3 Remove the fifth screw (callout 2) from the RFI shield.
Figure 22. RFI shield removal
4 Remove the RFI shield by lifting the shield up and off the hook
(callout 3).
