HP 33120A Installation Instructions

Calibration /Adjustment Procedure
After installing the Phase-Lock assembly, perform the frequency
adjustment procedure (CAL:SETup 0) on page 67 in the HP 33120A
Service Guide. Be sure to make the 1 kHz frequency measurement with
an accuracy of at least 8 digits (0.01 ppm). You may be required to
perform up to
three iterations of the frequency adjustment following
initial installation of the Phase-Lock assembly.
For complete details on performing a calibration, see chapter 4 in
the HP 33120A Service Guide.
5

HP 33120A Specifications

General

Frequency Range	100 µHz to 15 MHz
Waveforms	Sine, Square, Triangle, Ramp, Arbitrary
Amplitude Range	10 mVpp to 10 Vpp into 50 Ohms
Output Impedance	50 Ohms
Interface	GPIB
Function Generator Type	Arbitrary
Power Requirements	100/120/220/240 VAC ±10%, 50/60 Hz, 60 VA max
