HP 3336A - Page 102

Model
3336A/B/C
Performance
Tests
e.
If
the
certified
error
of
the
thermal
converter
being
used
was
given
in
dBm,
enter
this
e
value
in
the
Performance
Test
Record.
If
it
was
given
as
a
percentage,
convert
it
to
dBm
using
the
following
formula:
dBm
=
20log(1
-
Yerror/1000)
f.
Compute
the
amplitude
flatness
of
the
3336
at
each
output
and
frequency
setting
using
the
following
formula:
Reference
level
(from
Step
c)
—
336
Amplitude
setting
(from
Step
d)
+
Thermal
converter
error
(from
step
e)
= 3336 amplitude flatness
4-18.
Attenuator
Accuracy
Verification.
4-19.
This
performance
test
verifies
that
the
-hp-
3336
meets
the
attenuator
accuracy
specification
listed
in
Table
4-1
using
a
‘‘put
and
take’?
measurement
system
at
four
at-
tenuator
settings
and
three
test
frequencies.
It
is
preferred
that
this
test
be
performed
in
a
screen
room.
If
one
is
not
available,
an
electrically
‘‘clean’’
environment
is
a
must.
It
is
im-
portant
that
the
specified
cables
be
used
and
that
the
test
equipment
be
arranged
as
il-
lustrated.
Failure
to
follow
the
test
procedures
explicitly
can
result
in
erroneous
data.
NOTE
@
A
certification
program
is
available
to
verify
the
3336
attenuator
Specifications.
To
recertify,
the
attenuator
must
be
returned
to
Hewlett-Packard.
The
recertified
attenuator
will
be
returned
with
the
results
of
each
attenuation
setting.
Contact
your
nearest
Hewlett-Packard
Sales
Office
for
further
details.
A
list
of
these
of-
fices
is
provided
at
the
back
of
this
manual.
Required Equipment:
Attenuator (10 dB, 20 dB, 40 dB, 70 dB
attenuations)
with
Certification
-hp-
Model
355D
(2)
10
dB,
50
ohm
Coaxial
Attenuators
-hp-
Model
8491A
Option
010
75
ohm
to
50
ohm
Minimum
Loss
Impedance
Matching
Pad
-hp-
Model
85428B
50
ohm
Feedthru
Termination
-hp-
Model
11048C
Mixer
-hp-
Model
10514A
Synthesizer
-hp-
Model
3325A
Wave
Analyzer
-hp-
Model
3581A/C
DC
Voltmeter
-hp-
Model
3455A
DC
Power
Supply
-hp-
Model
6214A
20
dB
Amplifier
Q
Bit
Corp.
Model
QB-300
4-17
