6 Removal and replacement
procedures for Authorized Service
Provider parts
CAUTION: Components described in this chapter should only be accessed by an authorized service
provider. Accessing these parts can damage the computer or void the warranty.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to
http://partsurfer.hp.com, select your country or region, and
then follow the on-screen instructions.
Component replacement procedures
This chapter provides removal and replacement procedures for Authorized Service Provider only parts.
There are as many as 50 screws that must be removed, replaced, and/or loosened when servicing the
computer. Make special note of each screw size and location during removal and replacement.
Top cover
Description Spare part number
For use only on computer models equipped with a fingerprint reader 758051-001
For use only on computer models not equipped with a fingerprint reader 758050-001
Before removing the top cover, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
Component replacement procedures
67

Table of Contents

Other manuals for HP 350 G1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 350 G1 and is the answer not in the manual?

HP 350 G1 Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack, Silver
Country of originChina
Bus typeDMI
Tjunction100 °C
Processor cache3 MB
Processor cores2
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel® Core™ i3-4000 Mobile Series
Processor socketBGA 1168
Processor threads4
Processor codenameHaswell
Processor frequency1.7 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations4x1, 1x4
Thermal Design Power (TDP)15 W
Maximum number of PCI Express lanes10
Motherboard chipset-
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3L-SDRAM
Maximum internal memory- GB
Memory layout (slots x size)1 x 4 GB
HDD speed5400 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity500 GB
Number of HDDs installed1
Display surfaceMatt
Display diagonal15.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
On-board graphics card ID0xA16
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4400
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory2 GB
On-board graphics card base frequency200 MHz
On-board graphics card DirectX version12
On-board graphics card dynamic frequency (max)950 MHz
Audio systemDTS Sound
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
DisplayPorts quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pointing deviceTouchpad
Operating system installedWindows 8.1
Processor ARK ID75105
Processor package size40 x 24 x 1.5 mm
Intel ME Firmware Version9.5
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology version1.00
Intel Smart Response Technology version0.00
Battery capacity41 Wh
Battery life (max)- h
AC adapter power65 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth384 mm
Width261 mm
Height23.1 mm
Weight2300 g
