500-sheet paper feeder connectors
Figure 7-29 Connector locations for the 500-sheet paper feeder
General circuit diagram
The circuit diagram for the printer is provided in the following two figures. In addition, the 500-sheet
feeder is also provided following the general circuit diagrams.
J4001
J4004
J4003
J4002
J5012LA
J5012LB
J703
