454 Parts and diagrams ENWW
Introduction
The figures in this chapter show the major subassemblies in the printer and their component parts.
A table (materials list) follows each exploded assembly diagram. Each table lists the reference
designator (item number), the associated part number, and the description of each part.
Note When looking for a part number, pay careful attention to the voltage listed in the description column
to ensure that the part number selected is for the correct printer model.
Note In this manual, the abbreviation "PCB" stands for "printed circuit board assembly." Components
described as a PCB may consist of a single circuit board or a circuit board plus other parts, such as
cables and sensors.
Ordering parts
All standard part numbers are stocked and can be ordered from Hewlett-Packard Customer
Support-Americas (HPCS-A) or Hewlett-Packard Customer Support-Europe (HPCS-E). For
information about contacting HPCS-A or HPCS-E, see Parts and supplies, in chapter 2.
Note Parts that have no reference designator or part number are not field replaceable and cannot be
ordered.
Supplies and accessories
The items listed in Table 8-1 are available through your local authorized HP dealer. To find a
dealer near you, or if your local dealer is temporarily out of stock, call the HP Customer Information
Center at (800) 752-0900.
Note See Ordering related documentation and software, in chapter 2, for documentation part numbers.
Supplies and accessories are available directly from Hewlett-Packard at the following numbers:
● U.S.: (800) 538-8787
● Canada: (800) 387-3154, (Toronto) (416) 671-8383
● United Kingdom: 0734-441212
Contact your local HP Parts Coordinator for other local phone numbers.
Note Any item or part description followed by (HP3500) or (HP3700) indicates that the item or part is for
use for the HP Color LaserJet 3500 series printer or the HP Color LaserJet 3700 series printer only.
