HP X242 SFP+ SFP+ 1m Direct Attach Cable J9281B
HP X242 SFP+ SFP+ 3m Direct Attach Cable J9283B
HP X242 SFP+ SFP+ 7m Direct Attach Cable J9285B
HP X244 XFP SFP+ 1m Direct Attach Cable J9300A
HP X244 XFP SFP+ 3m Direct Attach Cable J9301A
HP X244 XFP SFP+ 5m Direct Attach Cable J9302A
Note 2 Localization required on orders without #B2B, #B2C or #B2E options. (in EMEA the
localization is required along with #B2C options)
Note 4 The following Transceivers install into this Switch:
HP X121 1G SFP LC LH Transceiver J4860C
HP X121 1G SFP LC LX Transceiver J4859C
HP X121 1G SFP LC SX Transceiver J4858C
HP X122 1G SFP LC BX-D Transceiver J9142B
HP X122 1G SFP LC BX-U Transceiver J9143B
HP X121 1G SFP RJ45 T Transceiver J8177C
HP X111 100M SFP LC FX Transceiver J9054C
HP X112 100M SFP LC BX-D Transceiver J9099B
HP X112 100M SFP LC BX-U Transceiver J9100B
HP X132 10G SFP+ LC ER Transceiver J9153A
HP X132 10G SFP+ LC SR Transceiver J9150A
HP X132 10G SFP+ LC LR Transceiver J9151A
HP X132 10G SFP+ LC LRM Transceiver J9152A
HP X242 SFP+ SFP+ 1m Direct Attach Cable J9281B
HP X242 SFP+ SFP+ 3m Direct Attach Cable J9283B
HP X242 SFP+ SFP+ 7m Direct Attach Cable J9285B
Box Level Integration CTO Models
CTO Solution Sku
HP 38xx CTO Switch Solution JG501A
SSP trigger sku
CTO Switch Chassis
HP 3800-24G-PoE+-2SFP+ Switch J9573A
24 RJ-45 autosensing 10/100/1000 PoE+ ports
2 fixed 1000/10000 SFP+ ports
min=0 \ max=2 SFP+ Transceivers
1 open stacking module slot
1 HP X312 100w Power Supply included
1 HP E3800 Switch Fan Tray (J9582A) included
1U - Height
See Configuration
Note:1, 2, 10, 11
QuickSpecs
HP 3800 Switch Series
Configuration
DA - 14152 Worldwide — Version 15 — January 16, 2014 Page 12

HP 3800 Series Specifications

General

Ports	4 x SFP
Routing Protocol	RIP
Management	Web, CLI, SNMP
Form Factor	Rack-mountable
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
