HP 3800 Series User Manual

HP 3800-24G-PoE+-2SFP+ Switch (J9573A)
Included accessories 1 HP 3800 Switch Fan Tray (J9582A)
1 HP X312 1000W 100-240VAC to 54VDC Power Supply (J9580A)
I/O ports and slots 24 RJ-45 autosensing 10/100/1000 PoE+ ports; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T:
full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE
802.3at PoE+)
2 fixed 1000/10000 SFP+ ports
1 RJ-45 serial console port
1 RJ-45 out-of-band management port
1 stacking module slot
Power supplies 2 power supply slots
1 minimum power supply required
includes: 1 x J9580A (HP X312 1000W 100-240VAC to 54VDC Power Supply)
Fan tray includes: 1 x J9582A
1 fan tray slot
Physical characteristics Dimensions 17.43(w) x 18.4(d) x 1.7(h) in (44.27 x 46.74 x 4.32 cm)
(1U height)
Weight 15.9 lb (7.21 kg) switch chassis with 1 power supply and fan tray installed
Memory and processor Processor HP ProVision ASIC/ARM @ 350 MHz; Freescale P2020 @ 1200 MHz, 4 GB flash,
2 GB SDRAM; packet buffer size: 18 MB dynamic
Mounting and enclosure Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface
mounting only
Performance 1000 Mb Latency < 2.8 µs (LIFO 64-byte packets)
10 Gbps Latency < 1.9 µs (LIFO 64-byte packets)
Throughput 65.4 million pps (64-byte packets)
Switching capacity 88 Gb/s
Routing table size 10000 entries (IPv4)
MAC address table size 65500 entries
Environment Operating temperature 32°F to 131°F (0°C to 55°C); max temperature is 45°C when transceivers are
installed
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft (3 km)
Acoustic Power: 49 dB, Pressure: 33.7 dB
Electrical characteristics Frequency 50/60 Hz
Maximum heat
dissipation
434 BTU/hr (457.87 kJ/hr)
AC voltage 100-120/200-240 VAC
QuickSpecs
HP 3800 Switch Series
Technical Specifications
DA - 14152 Worldwide — Version 15 — January 16, 2014 Page 25

HP 3800 Series Specifications

General

Ports	4 x SFP
Routing Protocol	RIP
Management	Web, CLI, SNMP
Form Factor	Rack-mountable
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
