HP 400D Organizational, Ds, Gs, And Depot Maintenance Manual

TM 11-6625-1514-15
Section VII
Group Assembly Parts List
Figure 7-2. Main Chassis Assembly (Sheet 2 of 2)
FIG. &
H-P MFR. OR MIL
DESCRIPTION UNITS
INDEX
STOCK PART
PER
NO.
NO. NO. 1234567
ASSY
7-2-33
1400-0074 INSULOID C3
.
CLAMP, LOOP (85682) . . . . . . . . . . 1
(ATTACHING PARTS)
2390-0009 COML
. SCREW, ASSEMBLED WASHER, 6-32 by
1
3/8 in. lg, s.s.
3050-0100 AN960-6
. WASHER, FLAT (88044) . . . . . . . . . 1
2420-0001 510-061810-01 .
NUT, ASSEMBLED WASHER (78189) . . .
1
*
------
-34 0160-0024 PKM 4P5 .
CAPACITOR, FIXED, PAPER
1
DIELECTRIC, 0.5 µf ±10%, 400 wvdc (14655)
-35
1400-0016
781
.
CLAMP, LOOP (83330) . . . . . . . . .
1
(ATTACHING PARTS)
2390-0001
COML
.
SCREW, ASSEMBLED WASHER, 6-32 by
1
1/2 in. lg, s.s. (78189)
2420-0001 510-061810-01
.
NUT, ASSEMBLED WASHER (78189) . . 1
---*---
-36
0687-4711
RC20GF471K
. RESISTOR, FIXED, COMPOSITION, . .
2
470 ohm ±10%, 1/2w (ML-R-11)
-37
0687-4741
RC20GF474K
.
RESISTOR, FIXED, COMPOSITION, . . 2
470K ±10%, 1/2w (MIL-R-11)
00102-3
7-5
