HP 400D Organizational, Ds, Gs, And Depot Maintenance Manual

TM 11-6625-1514-15
Section VII
Group Assembly Parts List
FIG. & H-P
MFR. OR MIL
DESCRIPTION UNITS
INDEX
STOCK PART
NO. NO. NO. 1 234567
ASSY
7-2-
-7
1220-0010 126
. SHIELD, ELECTRON TUBE (91662) . . .
-8
1923-0028
6CB6
. ELECTRON TUBE (24446) . . . . . . .
5
-9 1940-0001
5651 . ELECTRON TUBE (86684) . . . . . . . 1
-10
1921-0010
12B4 . ELECTRON TUBE (24446) . . . . . . . 1
-11 1933-0004 6U8 .
ELECTRON TUBE (24446) . . . . . . . . 1
-12
5080-0621
6CB6
.
ELECTRON TUBE (24446)
1
-13 1220-0005
429-.125
. BASE, Tube shield (91662) . . . . . . . .
1
-15 1200-0009 316PH-3702 . SOCKET, ELECTRON TUBE (91662) . . . 6
-16 1200-0008
44F-16388 .
SOCKET, ELECTRON TUBE (71785) . . .
2
-17
0180-0025
D32452
.
CAPACITOR, FIXED, Electrolytic, . 3
4 section,20 µf per section,450 wvdc
(56289)
-18 2100-0080
2100-0080
.
RESISTOR, VARIABLE, 1M ±30%, 0.2w . .
1
(28480)
-19
2100-0136 2100-0136 . RESISTOR, VARIABLE, 6K ±20%, 0.3w . .
1
(28480)
-20 0180-0028 D27390 . CAPACITOR, FIXED, ELECTROLYTIC, . 2
2 section, 1500 µf per section, 15 wvdc
(56280)
-21 1930-0014
6AX5-GT
. ELECTRON TUBE (86684) . . . . . . . . 1
-22 1400-0033 120D5-63AHS
.
RETAINER, ELECTRON TUBE (91506) .
1
-23
1200-0020
51A12272
.
SOCKET, ELECTRON TUBE (71785) . . .
1
-24
0400-0013
5P-1
GROMMET, PLASTIC (28520) . . . . . .
1
-25 (D,H,L)
8120-0050 CS-9941/PH151/
: CABLE ASSEMBLY, POWER, . . . . . . 1
7.5 FT ELECTRICAL (70903)
(H02)
H02-400D- H02-400D-PWR- .
CABLE ASSEMBLY, POWER, . . . . . .
1
PWR-CORD CORD
ELECTRICAL (28480)
(H02)
CS-9941/PH151/ . .
CABLE, POWER, ELECTRICAL (70003) 1
7.5 FT W/O PLUG
(H02)
1251-0037
MS24663
. . CONNECTOR, PLUG, ELECTRICAL
1
(96906)
-26 9100-0050 9100-0050
. TRANSFORMER, POWER, STEP-DOWN
1
AND STEP-UP (28480)
(ATTACHING PARTS)
2900-0001
510-101810-51
.
NUT, ASSEMBLED WASHER (78189) . . .
4
---*---
-27
0170-0057 S70375
.
CAPACITOR, FIXED, PAPER . . . . . .
1
DIELECTRIC, 5 µf ±10, 100 wvdc (56289)
-28
0130-0006 503-000-B2P0-28R
.
CAPACITOR, VARIABLE, CERAMIC
1
DIELECTRIC, 5-20 pf, 500 wvdc (72982) .
-29
0130-0001 503-000-D2P0-33R
.
CAPACITOR, VARIABLE, CERAMIC
1
DIELECTRIC, 7-45 pf, 500 wvdc (72982) .
-30 400D-6J
400D-6J
.
SHIELD, ROTARY SWITCH (28480) . . .
1
(ATTACHING PARTS)
2550-0007 COML
. SCREW, ASSEMBLED WASHER, 8-32 by
2
3/8 in. lg, s.s.
---*---
-31
400D-6K 400D-6K
. BRACKET, ANGLE (28480) . . . . . . . .
1
(ATTACHING PARTS)
2390-0009 COML
. SCREW, ASSEMBLED WASHER, 6-32 by
2
3/8 in. lg, s.s.
---*---
-32
400D-19A 400D-19A
. RANGE SWITCH ASSEMBLY (28480) . .
1
(See figure 7-3)
PER
1
7-4
00102-3
