HP 400D Organizational, Ds, Gs, And Depot Maintenance Manual

TM 11-6625-1514-15
Section VII
Group Assembly Parts List
FIG. &
H-P
MFR. OR MIL
DESCRIPTION
UNITS
INDEX STOCK PART
PER
NO.
NO.
NO.
1234567
ASSY
7-2-58
400D-65C 400D-65C . PRINTED CIRCUIT BOARD ASSEMBLY
1
(28480) (See figure 7-6)
(ATTACHING PARTS)
2390-0009
COML
.
SCREW, ASSEMBLED WASHER, 6-32 by
2
3/8 in. lg, s.s.
---*---
-59 0693-6821
RC42GF682K
.
RESISTOR, FIXED, COMPOSITION, . . .
1
6.8K ±10%, 2w (MIL-R-11)
-60 0170-0040
148P47392
. CAPACITOR, FIXED, PLASTIC . . . .
1
DIELECTRIC, 0.047 µf ±10%, 200 wvdc
(56289)
-61 0687-2251
RC20GF225K
. RESISTOR, FIXED, COMPOSITION, . . .
1
2.2M ±10%, 1/2w (MIL-R-11)
-62 0687-8251 RC20GF825K . RESISTOR, FIXED, COMPOSITION, . . . 1
8.2M ±10%, 1/2w (MIL-R-11)
-63 0160-0002 160P10396
. CAPACITOR, FIXED, PAPER DIELECTRIC,
1
0.01 µf ±10%, 600 wvdc (56289)
-64
400D-6F 400D-6F
.
MOUNTING PLATE, Shield (56289) . . .
1
(ATTACHING PARTS)
2420-0001
510-061810-01
.
NUT, ASSEMBLED WASHER (78189) . .
2
---*---
-65 1400-0025 777
.
CLAMP, LOOP (83380) . . . . . . . . . .
1
(ATTACHING PARTS)
2420-0001
510-061810-01
.
NUT, ASSEMBLED WASHER (78189) . .
2
*
------
-66 0761-0001
N25-8.2K . RESISTOR, FIXED, FILM, 8.2K ±5%, 1w .
1
(14674)
-67
0687-1251
RC20GF125K
.
RESISTOR, FIXED, COMPOSITION, . . . 1
1.2M ±10%, 1/2w (MIL-R-11)
-68
2100-0077 2100-0077
. RESISTOR, VARIABLE, 4 ohm ±20%, 1w .
1
(28480)
-69 0690-1001
RC32GF100K
.
RESISTOR, FIXED, COMPOSITION, . . .
1
10 ohm ±10%, 1w (MIL-R-11)
-70
1882-0005 61-6911
. RECTIFIER, METALLIC (81482) . . .
1
(ATTACHING PARTS)
2370-0009
MS35239-42
.
SCREW, MACHINE (96906) . . . . . . . .
1
2420-0001
510-061810-01 .
NUT, ASSEMBLED WASHER (78189) . .
1
---*---
-71
2110-0007 MDL-1
. FUSE, CARTRIDGE, 1 amp, 250v, slow . 1
blow for 115v (71400)
-72 1400-0084 342014
.
FUSEHOLDER (75915) . . . . . . . . . . 1
-73
0687-3351
RC20GF335K . RESISTOR, FIXED, COMPOSITION,
1
3.3M ±10%, 1/2w (MIL-R-11)
-74 0690-1831
RC32GF183K
. RESISTOR, FIXED, COMPOSITION, . . .
1
18K ±10%, 1w (MIL-R-11)
-75 0160-0044
160P27296
.
CAPACITOR, FIXED, PAPER . . . . .
1
DIELECTRIC, 0.0027 µf ±10%, 600 wvdc
(56289)
-76 400D-1A
400D-1A
PANEL, Rear (28480). . . . . . . . .
-77
.
1
400D-1B
400D-1B
.
CHASSIS, ELECTRICAL EQUIPMENT .
1
(28480)
F1 fuse (230 v only) 1/2 amp
slow blow
2110-0008
00102-3
7-7
