Getting Started
Making a Measurement
When you use the HP 4156A, connect as follows:
HP 4156A cable HP 16442A
Intlk ( Interlock/LED
1
) Intlk
SMU 1 ( Kelvin triaxial
2
) SMU 1
SMU 2 ( Kelvin triaxial
2
) SMU 2
SMU 3 ( Kelvin triaxial
2
) SMU 3
HP 4156A cable HP 16442A
VSU 1 ( Coaxial
3
) VSU 1
VSU 2 ( Coaxial
3
) VSU 2
VMU 1 ( Coaxial
3
) VMU 1
VMU 2 ( Coaxial
3
) VMU 2
1 Interlock/LED cable: HP 16493J
2 Kelvin triaxial cable: HP part number 04155-61602
3 Coaxial cable: HP 16493B.You do not need to connect VSUs and VMUs for this measurement.
Kelvin triaxial cable
HP 16442A
HP 4156A
Coaxial cable
Interlock/LED
cable
Connecting HP 4156A to HP 16442A Test Fixture
5
