Getting Started
Making a Measurement
Step 2. Mount your DUT on the test xture
1. Select a suitable socket module for your DUT.
2. Mount the socket module on the test xture.
HP 16442A Test Fixture
Socket module
3. Mount your DUT on the socket module.
4. Make connections with four connection cables (miniature banana { pin
plug).
You make the following connections:
Source|SMU1
Gate|SMU2
Drain|SMU3
Substrate|SMU1
Both the source and substrate terminals are connected to SMU1.
5. After nishing connections, shut the lid of the test xture.
6
To Next Page
