high limit value, the cursor will move automatically to the next
sweep p oint eld. Repeat steps 3 through 7.
System Menu
The system menu on this page allows you to perform the following
control functions.
Load/Store
Clear Table
Printer
These functions, except for the clear table function, are the same
as the functions in the system menu on the
MEAS DISPLAY
page. (A description of each function is given in \System Menu" in
Chapter 3 on page 3-19.) So in the case of the clear table function,
the description and pro cedure are given, and in the case of the other
functions, only the pro cedure is given.
Load/Store Function
Perform the following steps on the
LIST SWEEP SETUP
page to
Load/Store the control settings from/to internal non-volatile memory
or an external memory card.
1. Set all controls.
2. Move the cursor to the
SYS MENU
eld on the
LIST SWEEP
SETUP
page.
3. If you are using a memory card insert the memory card to the
MEMORY card slot.
4. Press
NNNNNNNNNNNNNNNNN
STORE
when you want to use the store function. The
message
Enter record number to STORE
will be displayed on the
system message line.
Press
NNNNNNNNNNNNNN
LOAD
when you want to use the load function. The message
Enter record number to LOAD
will be displayed on the system
message line.
5. Enter the record number using the numeric entry keys and
4
ENTER
5
to Load/Store the current control settings.
Clear Table Function
This function allows you to clear all of the list sweep p oints and
limits. When you change from the currentsweep parameter to the
other sweep parameter, this function must be used.
Perform the following steps to set only all of the op erations on the
LIST SWEEP SETUP
page to the p ower on default settings.
1. Move the CURSOR to the
SYS MENU
eld.
2. Press
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
CLEAR TABLE
. Then the message
Clearing table, Are
you sure?
will be displayed, and the following softkeys will b e
displayed.
4-54 MEAS SETUP Menu
