NNNNNNNN
ON
NNNNNNNNNNN
OFF
2. Use the softkeys to set the b eep er function to the ON or OFF.
HP-IB Setting
Description
All HP 4284As except those with Option 109 Delete HP-IB Interface
are equipped with an HP-IB interface so they can b e controlled via
the HP-IB bus. The HP 4284A can be linked to other instruments
and computers to form an automated measurement system. The
status of the HP-IB interface installed/not installed is monitored on
this SYSTEM CONFIG page ( HP-IB I/F ).
The HP-IB address and the Talk Only mo de can be set on this page.
How to Set the HP-IB Address
Perform the following steps to set HP-IB address.
1. Move the cursor to the HP-IB ADDRESS eld on the
SYSTEM
CONFIG page.
2. Enter the HP-IB address using the numeric entry keys, and press
4
ENTER
5 .
How to Set the Talk Only Mode
Perform the following steps to set the HP 4284A to the T
alk Only
mo de (ON). To set the HP 4284A to the addressable mo de, p erform
the following steps to set the Talk Only mo de to OFF.
1. Move the cursor to the TALK ONLY eld on the SYSTEM
CONFIG page. The following softkeys will b e displayed in the
softkey lab el area.
NNNNNNNN
ON
NNNNNNNNNNN
OFF
2. Use the softkeys to set the T
alk Only mo de to ON (Talk only), or
to OFF (addressable).
Handler Interface
Setting
Description
When the HP 4284A is equipped with an Option 201 or 202 Handler
Interface, the 36-pin Amphenol connector on the rear panel is used
to interface b etween the HP 4284A and the handler to pass control
input/output signals and the comparator function bin judgmen
t
results. Refer to the HP 4284A Option 201 or 202 Operation Note.
5-8 Catalog/System Configuration
