LIST SWEEP SETUP
SYSTEM CONFIG
Softkey Area
The last six character p ositions of each line are reserved for softkey
lab els. The softkeys displayed corresp ond to the eld at the cursor's
position on the LCD.
Measurement Data/Conditions Area
This area is where measurement results and measurement conditions
are displayed.
Note
Under certain conditions one of the following messages maybe
displayed instead of the measurement results.
\
UNBAL
": This message is displayed when the imp edance of the
device exceeds the range of the analog measurement
circuit's capability.
\
ADC ERR
": This message is displayed when the A/D converter in
the measurement circuit is not functioning.
\
------
": This message is displayed and is called \overow"
when the analog measurement circuit can measure
the device, but the data format used will not hold
the calculated results.
\
INFINITY
": This message is displayed when an attempt is made
to divide by zero during parameter calculation. For
example, if you set the 1 % measurement function
without setting the reference value, this message will
be displayed.
Input Line Area
This area is the input line where numeric input data entered with the
front panel keys is displayed.
System Message Area
This area is where system messages, comments, and error messages
are displayed.
2-8 Overview
