4. Select and press a softkey to set the measurement function. If the
softkey you want is not displayed, press
NNNNNNNNNNNNNNNNNNNNNNNNNN
more 3/6 to display the
following set of softkeys.
NNNNNNNNNNNNNN
Ls-D
NNNNNNNNNNNNNN
Ls-Q
NNNNNNNNNNNNNNNNNNNN
Ls-Rs>
NNNNNNNNNNNNNNNNNNNNNNNNNN
more 4/6
5. Select and press a softkey to set the measurement function. If the
softkey you want is not displayed, press
NNNNNNNNNNNNNNNNNNNNNNNNNN
more 4/6 to display the
following set of softkeys.
NNNNNNNNNNN
R-X
NNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Z-  (deg)
NNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Z-  (rad)
NNNNNNNNNNNNNNNNNNNNNNNNNN
more 5/6
6. Select and press a softkey to set the measuremen
t function. If the
softkey you want is not displayed, press
NNNNNNNNNNNNNNNNNNNNNNNNNN
more 5/6 to display the
following set of softkeys.
NNNNNNNNNNN
G-B
NNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Y-  (deg)
NNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Y-  (rad)
NNNNNNNNNNNNNNNNNNNNNNNNNN
more 6/6
7. Select and press a softkey to set the measurement function.
When
NNNNNNNNNNNNNNNNNNNNNNNNNN
more 6/6 is pressed, the softkeys shown in step 1 will b e
displayed. Retry steps 1 through 7 if you missed the function you
were lo oking for.
Measurement Range
Description
The HP 4284A has eight measurement ranges: 10, 100, 300, 1
k, 3 k, 10 k, 30 k, and 100 k. When Option 001 is installed,
the HP 4284A has nine measurement ranges: 1, 10, 100, 300,
1 k, 3 k, 10 k, 30 k, and 100 k. The measurement range is
selected according to the DUT's imp edance even if measurement
parameter is capacitance or inductance.
Figure 3-3 shows the display range and eective measuring range for
each measurement range while in the imp edance mo de (
j Z j , R, X).
For example, 50 k DUT imp edance can b e measured using from
