HP 430 - Memory Specifications; Hard Drive Options

EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.
HP 90W AC Adapter Dimensions 5.0 x 2.0 x 1.18 in (12.7 x 5.1 x 3.0 cm)
Weight 0.77 lb (350 g)
Input 100 to 240 VAC
Input Efficiency 87% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.6 A at 90 VAC
Output Output power 90W
DC output 18.5V
Hold-up time 5 msec at 115 VAC input
Output current limit 11A, Over voltage protection- 29V max automatic
shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 41° to 95° F (5° to 35° C)
Non-operating (storage)
temperature
-4° to 185° F (-20° to 85° C)
Altitude 0 to 5,000 ft (0 to 1,524 m)
Humidity 20% to 95%
Storage Humidity 10% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.
6-Cell (47 WHr) Lithium-
Ion battery
Dimensions (HxWxL) 0.85 x 2.06 x 8.07 in (2.17 x 5.23 x 20.5 cm)
Weight 0.7 lb (0.327 kg)
Cells/Type 6-cell Lithium-Ion
Energy Watt-hour Capacity 47 WHr
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (-10° to 60° C)
Non-operating -4° to 140° F (-20° to 60° C)
Battery Re-Charge Time System in OFF Mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Technology Charges the battery up to 90% within 90 minutes
when system is OFF
QuickSpecs
HP 430 Notebook PC
HP 630 Notebook PC
Technical Specifications
DA - 13963 Worldwide — Version 11 — July 23, 2012 Page 13
