Clearing jams from the output-bin areas
NOTE If media is jammed in the top output area, but most of the media is still inside the
printer, it is best to remove it through the rear door.
1. Open the rear door.
2. Slightly lift up the rear door, and then, on the inside of the door, lift up on the middle portion of
the black assembly to release the clips. Let the rear door drop completely open.
126 Chapter 7 Problem solving ENWW
