Torx T8M2.5×4.0 screw

Color Quantity Length Thread Head diameter

Black 4 4.0 mm 2.5 mm 5.0 mm

Where used: 2 screws that secure the speaker to the computer

Where used: One screw that secures the top cover to the base enclosure

Torx T8M2.5×4.0 screw 109

Other manuals for HP 550

Need help?

Do you have a question about the HP 550 and is the answer not in the manual?

General

Storage	120 GB HDD
Graphics	Intel GMA X3100
Battery	6-cell Lithium Ion
Wireless	802.11a/b/g
Processor	Intel Core 2 Duo T5270 / 1.4 GHz
RAM	1 GB DDR2
Display	15.4-inch WXGA (1280 x 800)
Operating System	Windows Vista Home Basic
Chipset	Mobile Intel GM965 Express
Optical Drive	DVD±RW
Ports	3 x USB 2.0, VGA, LAN, Modem, Headphone output, Microphone input
