Operation and Service Manual
Performance Tests Procedures
Network analyzer
(0.1-110 MHz)
System with a swept source capable of measur-
ing the amplitude of reflected signals return loss.
Frequency range: 0.1 to 1300 MHz
Resolution: 0.25 dB
Accuracy: ±6%
HP 8407A P
Network analyzer
(0.11 -1.4 GHz)
HP 8410A
Phase-magnitude
display
HP 8412A
Harmonic fre-
quency converter
HP 8411A
S-parameter test set HP 8745A
Universal extension HP 11604A
Transmission kit HP 11651A
Accessory kit HP 11570A
Spectrum analyzer
RF section
Frequency range: 10-1300 MHz
Dynamic range: 60 dB minimum
Scan width: 800 MHz minimum
Spurious responses: <
−60 dB
Absolute amplitude calibration.
Variable persistence display.
HP 8555A P
Spectrum analyzer
IF section
HP 8552A
Display section HP 141T
Noise figure meter Frequency range: 0.1-1300 MHz
Noise figure range: 0-15 dB
Accuracy: ±0.5 dB
Excess noise ratio: 6.3 ±0.5 dB
HP 342A P
VHF noise source HP 343A
UHF noise source HP 349A
RMS voltmeter Voltage range: 1mV to 1V (full range)
Frequency range: 10 Hz to 10 MHz
Meter accuracy: ±5%
HP 3400A P,A,T
Power meter
Rower range: −20 dBm to +10 dBm
Frequency range: 10-1300 MHz
Meter accuracy:
±1%
HP 432A/478A P
Amplifier Gain: 24 dB
Noise: <8 dB
Frequency range: 0.1-130 MHz
HP 8447D P
Table 4 Recommended Test Equipment and Accessories
Instrument Type Minimum Specifications Suggested Model
Use
