HP 8447D - Page 20

18 DRAFT
Operation and Service Manual
Performance Tests Procedures
a.P=Performance Test, A=Adjustments, T=Troubleshooting
Digital voltmeter Voltage range: 0-60V
Accuracy: ±0.05% ±1 digit
HP 3440A/3444A A, T
Double balanced
mixers
Frequency range: 200-1300 MHz Sage Laboratories
2500 Series
P
Low pass filter Cutoff frequency: 400 MHz
Attenuation: >60 dB at 800 and 1200 MHz
Cir-Q-Tel
FLT/2 Series
P
Attenuator 10 dB, 0.1-1300 MHz HP 8491A
Option 010
P
Attenuator 20 dB, 0.1-1300 MHz HP 8491A
Option 020
P
Termination 50 Ω (BNC) HP 11593A P
Termination 50 Ω (Type-N) HP 908A P
Adapter Type-N female to BNC male UG-349A/U P
Adapter BNC female to Type-N male UG-209A/U P
Tee BNC UG-274B/U P
Cable assembly Type-N connectors HP 11500A P
Cable assembly (5) BNC connectors HP 10503A P
Cable assembly BNC with test clips attached HP 10501A A,T
Adapter BNC female to binding post HP 10111A P, A, T
Adapter BNC male to BNC male UG-491A/U P
Table 4 Recommended Test Equipment and Accessories
Instrument Type Minimum Specifications Suggested Model
Use
a
