HP 8447D - Page 41

DRAFT 39
Operation and Service Manual
Parts and Service
W2 08447-20006 9 1 Cable assy: BNC INPUT 28480 08447-20006
W3 08447-20003 6 1 Cable assy: Type-N OUTPUT
(Opt 010 and 011 only)
28480 08447-20003
W3 08447-20007 0 1 Cable assy: BNC OUTPUT 28480 08447-20007
W4 08447-20004 7 1 Cable assy: Type-N INPUT (Opt 011) 28480 08447-20004
W4 08447-20008 1 1 Cable assy: BNC INPUT (Opt 001) 28480 08447-20008
W5 08447-20005 8 1 Cable assy: Type-N OUTPUT (Opt 011) 28480 08447-20005
W5 08447-20009 2 1 Cable assy: BNC OUTPUT (Opt 001) 28480 08447-20009
W6
08447-20014
9 1 Cable assy: jumper (Opt 011 only) 28480 08447-20014
XF1 Fuseholder (includes the following parts)
XF1MP1 2110-0564 8 1
Fuseholder body 12A max for UL
28480 2110-0564
XF1MP2 2110-0565 9 1 Fuseholder cap 12A max for UL 28480 2110-0565
XF1MP3 2110-0569 3 1 Nut-fuseholder thread 28480 2110-0569
XQ1 0340-1114 1 Insulator: xstr mounting (TO-3) 28480 0340-1114
XF1MP4 1400-0090 9 1 Washer 28480 1400-0090
0360-0368 7 1 Termination: solder stud 78189 2168-12-01
0900-0016 8 1 O-ring 0.688” OD 00000 OBD
Table 8 HP 8447D Replaceable Parts
Ref
Des
HP Part
Number
CD qty Description
Mfr
Code
Mfr Part
Number
