Operation and Service Manual
Parts and Service
Table 9 HP 8447E Replaceable Parts
Ref
Des
HP Part
Number
CD qty Description
Mfr
Code
Mfr Part
Number
A1 08447-60045 0 1 Board Assy: Power Supply 28480 08447-60045
A1C1 0150-0024 7 1 C: fixd cer 0.02 uF +80-20% 600 Vdcw 71590 Type DD 203
A1C2 0180-0228 6 1 C: fixd elect 22 uF 10% 15 Vdcw 56289 150D226X9015B2DYS
A1C3 0160-0162 5 1 C: fixd my 0.022 uF 10% 200 Vdcw 56289 192P22392-PTS
A1C4 0180-0116 1 1 C: fixd elect 6.8uF 10% 35 Vdcw 56289 150D685X9035B2DYS
A1C5 0180-1819 3 1 C: fixd elect 100 uF +75-10% 50 Vdcw 56289 150D226X9015B2DYS
A1CR1 1901-0743 1 4 Diode: pwr rect IN4004 400VIA DO-41 28480 1901-0743
A1CR2 1901-0743 1 Diode: pwr rect IN4004 400VIA DO-41 28480 1901-0743
A1CR3 1901-0743 1 Diode: pwr rect IN4004 400VIA DO-41 28480 1901-0743
A1CR4 1901-0743 1 Diode: pwr rect IN4004 400VIA DO-41 28480 1901-0743
A1CR5 1920-3002 1 1 Diode: breakdown 3.16V 5% 28480 1920-3002
A1CR6 1902-0761 5 1 Diode: breakdown 5.9 - 6.5V 12954 1N821
A1CR7 1901-0025 2 2 Diode: silicon 100 mA/1V 07263 FD 2387
A1CR8 1902-3268 3 1 Diode: breakdown 26.1V 5% 28480 1902-3268
A1CR9 1884-0073 2 1 Thyristor-scr TO-5 VRRM=100 01921 SCR1400
A1CR10 1901-0025 2 Diode: silicon 100 mA/1V 07263 FD 2387
A1F1 2110-0012 0 2 Fuse: 0.5 amp 250V 04703 312.500
A1F1 2110-0726 9 1 Clip: fuse: 0.250” diam. 91506 6008-32CN
A1Q1 1853-0012 4 1 Xstr: si PNP 80131 2N2904A
A1Q2 1854-0022 8 1 Xstr: si NPN 07263 S17843
A1Q3 1854-0071 7 3 Xstr: si NPN (selected from 2N3704) 28480 1854-0071
A1Q4 1854-0071 7 Xstr: si NPN (selected from 2N3704) 28480 1854-0071
A1Q5 1854-0071 7 Xstr: si NPN (selected from 2N3704) 28480 1854-0071
A1R1 0757-0836 6 1 R: fixd met flm 7.50 kohm 1% 1/2W 28480 0757-0836
A1R2 0698-7238 9 1 R: fixd met flm 1.78 kohm 1% 1/8W 28480 0698-7238
A1R3 0757-0836 5 1 R: fixd met flm 7.50 kohm 1% 1/2W 28480 0757-0836
A1R4 0811-1832 8 1 R: fixd WW 1.5 ohm 5% Type V 1W 28480 0811-1832
A1R5 0698-0089 4 1 R: fixd met flm 1780 ohm 1% 1/8W 28480 0698-0089
A1R6 0698-0083 8 1 R: fixd met flm 1.96 kohm 1% 1/8W 28480 0698-0083
A1R7 0698-3440 7 1 R: fixd met flm 196 ohm 1% 1/8W 28480 0698-3440
A1R8 0757-0416 7 1 R: fixd met flm 511 ohm 1% 1/8W 28480 0757-0416
A1R9 2100-1758 3 1 R: var ww 1 kohm 5% Type V 1W 28480 2100-1758
A1R10 0698-3154 0 1 R: fixd met flm 4.22 kohm 1% 1/8W 28480 0698-0083
A1R11 0757-1094 9 1 R: fixd met flm 1.47 kohm 1% 1/8W 28480 0757-1094
