DRAFT 41
Operation and Service Manual
Parts and Service
A1R12 0698-3442 9 1 R: fixd met flm 237 ohm 1% 1/8W 28480 0698-3442
A1R13 0757-0180 2 1 R: fixd met flm 31.6 ohm 1% 1/8W 28480 0757-0180
A1R14 0757-0401 0 R: fixd met flm 100 ohm 1% 1/8W 28480 0757-0401
C1 0180-2805 9 1 C: fixd elect 850 uF +50-10% 75VDCW 28480 0180-2805
C2 0160-2049 1 1 C: fixd cer feedthru 5000 pF +80-20% 28480 0160-2049
C3 0180-0291 3 1 C: fixd elect 1.0 uF 10% 35 VDCW 56289 150D105X9035A2DYS
DS1 2140-0244 4 1 Lamp: glow miniature 95V 87034 A1H
F1 2110-0012 1 Fuse: 0.5A 250V 04703 312.500
J1 1251-2357 8 1 Socket: 3-pin male power
(part of rear panel)
82389 EAC-301
J2 Part of W2
J3 Part of W3
L1 9100-1618 1 2 Coil: molded choke 5.60 uH 28480 9100-1618
L2 9100-1618 1 Coil: molded choke 5.60 uH
(Opt 001 and 011 only)
28480 9100-1618
MP1 08447-00005 6 1 Insulator: top cover 28480 08447-00005
Q1 1854-0063 7 1 Xstr: si NPN 80131 2N3055
R1 0683-2735 0 1 R: fixd comp 27 kohm 5% 1/4W 01121 CB 2735
S1 3101-2139 9 1 Switch-pb DPST-NO altng 10.5A 250Vac 28480 3101-2139
S1 3101-2195 1 for HP 8447D, serial no. 2727A06246
for HP 8447E, serial no. 2727A02669
for HP 8447F, serial no. 2805A03498
28480 3101-2195
S1 0590-0012 5 2 Nut: knurled 15/32-32 04009 899U-3
S2 3101-1234 3 1 Switch: slide DPDT 82389 11A-1242
T1 9100-2894 7 1 Transformer: power 28480 9100-2894
U1 5086-7768 7 1 Hybrid mc:power-ampl 0.1-1300 MHz 28480 5086-7767
U1 08447-60029 5086-7768 replacement kit (for use with
08447-60045 assy).
28480 08447-60029
W1 8120-1348 5 1 Cable assy: power, detachable 70903 KHS-7041
W2 08447-20002 5 1 Cable assy: Type-N INPUT
(Opt 010 and 011 only)
28480 08447-20002
W2 08447-20006 9 1 Cable assy: BNC INPUT 28480 08447-20006
W3 08447-20003 6 1 Cable assy: Type-N OUTPUT
(Opt 010 and 011 only)
28480 08447-20003
W3 08447-20007 0 1 Cable assy: BNC OUTPUT 28480 08447-20007
Table 9 HP 8447E Replaceable Parts
Ref
Des
HP Part
Number
CD qty Description
Mfr
Code
Mfr Part
Number
