HP 8447D - Page 44

42 DRAFT
Operation and Service Manual
Parts and Service
XF1 Fuseholder (includes the following parts)
XF1MP1 2110-0564 8 1
Fuseholder body 12A max for UL
28480 2110-0564
XF1MP2 2110-0565 9 1 Fuseholder cap 12A max for UL 28480 2110-0565
XF1MP3 2110-0569 3 1 Nut-fuseholder thread 28480 2110-0569
XQ1 0340-0664 1 Insulator: xstr mounting (TO-3) 28480 0340-0664
XF1MP4 1400-0090 9 1 Washer: lock sst for 1/2 thread 28480 1400-0090
0360-0368 7 1 Termination: solder stud 78189 2168-12-01
0900-0016 8 1 O-ring 0.688” OD 00000 OBD
Table 9 HP 8447E Replaceable Parts
Ref
Des
HP Part
Number
CD qty Description
Mfr
Code
Mfr Part
Number
