HP 8447D - Page 45

DRAFT 43
Operation and Service Manual
Parts and Service
Table 10 HP 8447F Replaceable Parts
Ref
Des
HP Part
Number
CD qty Description
Mfr
Code
Mfr Part
Number
A1 08447-60045 0 1 Board Assy: Power Supply 28480 08447-60045
A1C1 0150-0024 7 1 C: fixd cer 0.02 uF +80-20% 600 Vdcw 71590 Type DD 203
A1C2 0180-0228 6 1 C: fixd elect 22 uF 10% 15 Vdcw 56289 150D226X9015B2DYS
A1C3 0160-0162 5 1 C: fixd my 0.022 uF 10% 200 Vdcw 56289 192P22392-PTS
A1C4 0180-0116 1 1 C: fixd elect 6.8uF 10% 35 Vdcw 56289 150D685X9035B2DYS
A1C5 0180-1819 3 1 C: fixd elect 100 uF +75-10% 50 Vdcw 56289 150D226X9015B2DYS
A1CR1 1901-0743 1 4 Diode: pwr rect IN4004 400VIA DO-41 28480 1901-0743
A1CR2 1901-0743 1 Diode: pwr rect IN4004 400VIA DO-41 28480 1901-0743
A1CR3 1901-0743 1 Diode: pwr rect IN4004 400VIA DO-41 28480 1901-0743
A1CR4 1901-0743 1 Diode: pwr rect IN4004 400VIA DO-41 28480 1901-0743
A1CR5 1920-3002 1 1 Diode: breakdown 3.16V 5% 28480 1920-3002
A1CR6 1902-0761 5 1 Diode: breakdown 5.9 - 6.5V 12954 1N821
A1CR7 1901-0025 2 2 Diode: silicon 100 mA/1V 07263 FD 2387
A1CR8 1902-3268 3 1 Diode: breakdown 26.1V 5% 28480 1902-3268
A1CR9 1884-0073 2 1 Thyristor-scr TO-5 VRRM=100 01921 SCR1400
A1CR10 1901-0025 2 Diode: silicon 100 mA/1V 07263 FD 2387
A1F1 2110-0012 0 2 Fuse: 0.5 amp 250V 04703 312.500
A1F1 2110-0269 9 1 Clip: fuse: 0.250” diam. 91506 6008-32CN
A1Q1 1853-0012 4 1 Xstr: si PNP 80131 2N2904A
A1Q2 1854-0022 8 1 Xstr: si NPN 07263 S17843
A1Q3 1854-0071 7 3 Xstr: si NPN (selected from 2N3704) 28480 1854-0071
A1Q4 1854-0071 7 Xstr: si NPN (selected from 2N3704) 28480 1854-0071
A1Q5 1854-0071 7 Xstr: si NPN (selected from 2N3704) 28480 1854-0071
A1R1 0757-0836 6 1 R: fixd met flm 7.50 kohm 1% 1/2W 28480 0757-0836
A1R2 0698-7238 9 1 R: fixd met flm 1.78 kohm 1% 1/8W 28480 0698-7238
A1R3 0757-0836 5 1 R: fixd met flm 7.50 kohm 1% 1/2W 28480 0757-0836
A1R4 0811-1732 8 1 R: fixd WW 1.5 ohm 5% Type V 1W 28480 0811-1732
A1R5 0698-0089 4 1 R: fixd met flm 1780 ohm 1% 1/8W 28480 0698-0089
A1R6 0698-0083 8 1 R: fixd met flm 1.96 kohm 1% 1/8W 28480 0698-0083
A1R7 0698-3440 7 1 R: fixd met flm 196 ohm 1% 1/8W 28480 0698-3440
A1R8 0757-0416 7 1 R: fixd met flm 511 ohm 1% 1/8W 28480 0757-0416
A1R9 2100-1758 3 1 R: var ww 1 kohm 5% Type V 1W 28480 2100-1758
A1R10 0698-3154 0 1 R: fixd met flm 4.22 kohm 1% 1/8W 28480 0698-0083
A1R11 0757-1094 9 1 R: fixd met flm 1.47 kohm 1% 1/8W 28480 0757-1094
