HP 8447D - Page 49

DRAFT 47
Operation and Service Manual
Parts and Service
A1R12 0698-3442 9 1 R: fixd met flm 237 ohm 1% 1/8W 28480 0698-3442
A1R13 0757-0180 2 1 R: fixd met flm 31.6 ohm 1% 1/8W 28480 0757-0180
A1R14 0757-0401 0 R: fixd met flm 100 ohm 1% 1/8W 28480 0757-0401
A2 08447-60038 1 Board Assy: H64 Amplifier 28480 08447-60038
A2C1 0160-4441 4 C: fixd cer 0.47 uF 50 Vdcw
A2C2 0160-4441 C: fixd cer 0.47 uF 50 Vdcw
A2C3 0160-4441 C: fixd cer 0.47 uF 50 Vdcw
A2C4 0160-4441 C: fixd cer 0.47 uF 50 Vdcw
A2J3 1250-1220 2 Conn: RF M SMC (output)
A2J4 1250-1220 Conn: RF M SMC (input)
A2L1 9140-0351 1 Coil: 18 nH 5%
A2L2 9100-2486 1 Coil: 330 nH 5%
A2MP1 1205-1220 2 Heatsink: T05/T39
A2MP2 1205-1220 Heatsink: T05/T39
A2MP3 3050-0082 2 Washer: fiber 0.116 ID 4
A2MP4 3050-0082 Washer: fiber 0.116 ID 4
A2Q1 1813-0213 2 IC: MWA130M1 amp
A2Q2 1813-0213 IC: MWA130M1 amp)
A2R1 0698-3631 1 R: fixd 330 ohm 5% 2W
A2R2 0698-3629 1 R: fixd 270 ohm 5% 2W
C1 0180-2805 9 1 C: fixd elect 850 uF +50-10% 75VDCW 28480 0180-2805
C2 0160-2049 1 1 C: fixd cer feedthru 5000 pF +80-20% 28480 0160-2049
C3 0180-0291 3 1 C: fixd elect 1.0 uF 10% 35 VDCW 56289 150D105X9035A2DYS
C4 0160-2049 1 C: fixd cer 5000 pF +80-20% 200VDCW 28480 0180-2805
DS1 2140-0244 4 1 Lamp: glow miniature 95V 87034 A1H
F1 2110-0012 1 Fuse: 0.5A 250V 04703 312.500
J1 1251-2357 8 1 Socket: 3-pin male power
(part of rear panel)
82389 EAC-301
J2 Part of W2
J3 Part of W3
J4 Part of W4
J5 Part of W5
Table 11 HP 8447F H64 Replaceable Parts
Ref
Des
HP Part
Number
CD qty Description
Mfr
Code
Mfr Part
Number
