48 DRAFT
Operation and Service Manual
Parts and Service
L1 9100-1618 1 2 Coil: molded choke 5.60 uH 28480 9100-1618
L2 9100-1618 1 Coil: molded choke 5.60 uH
(Opt 001 and 011 only)
28480 9100-1618
MP1 08447-00005 6 1 Insulator: top cover 28480 08447-00005
MP5 08447-00082 1 Bracket: pc board support 28480 08447-00082
MP6 08447-00069 1 CATV cable assy cover 28480 08447-00069
Q1 1854-0063 7 1 Xstr: si NPN 80131 2N3055
R1 0683-2735 0 1 R: fixd comp 27 kohm 5% 1/4W 01121 CB 2735
S1 3101-2195 1 Switch-pb DPST 28480 3101-2195
S1 0590-0012 5 2 Nut: knurled 15/32-32 04009 899U-3
S2 3101-1234 3 1 Switch: slide DPDT 82389 11A-1242
T1 9100-2894 7 1 Transformer: power 28480 9100-2894
U1 5086-7767 7 1 Hybrid mc:pre-ampl 0.1-1300 MHz
(Opt 001 and 011 only)
28480 5086-7767
U1 08447-60044 5086-7767 replacement kit (for use with
08447-60045 assy).
28480 08447-60044
W1 8120-1348 5 1 Cable assy: power, detachable 70903 KHS-7041
W2 08447-20043 1 Cable assy: Type-N INPUT 28480 08447-20043
W3 08447-20044 1 Cable assy: Type-N OUTPUT 28480 08447-20044
W4 08447-20051 1 Cable assy: Type-N INPUT flexible coax-
ial
28480 08447-20051
W5 08447-20046 1 Cable assy: Type-N OUTPUT flexible
coaxial
28480 08447-20046
XA1
1251-0135 1
Part of main deck: 15-pin connector)
2848
0
1251-0135
XF1 Fuseholder (includes the following parts)
XF1MP1 2110-0564 8 1
Fuseholder body 12A max for UL
28480 2110-0564
XF1MP2 2110-0565 9 1 Fuseholder cap 12A max for UL 28480 2110-0565
XF1MP3 2110-0569 3 1 Nut-fuseholder thread 28480 2110-0569
XF1MP4 1400-0090 9 1 Washer: lock sst for 1/2 thread 28480 1400-0090
XQ1 0340-0664 1 Insulator: xstr mounting (TO-3) 28480 0340-0664
0360-0368 7 1 Termination: solder stud 78189 2168-12-01
0900-0016 8 1 O-ring 0.688” OD 00000 OBD
Table 11 HP 8447F H64 Replaceable Parts
Ref
Des
HP Part
Number
CD qty Description
Mfr
Code
Mfr Part
Number
