Heat sink

Description Spare part number

Heat sink (includes a heat sink clip and replacement thermal material)

Thermal Material Kits

For use with the Quad Core processor and nVidia graphics card

501116-001

For use with the Quad Core processor and ATI graphics card 495074-001

For use with the Dual-Core processor and nVidia graphics card 495075-001

For use with the Dual-Core processor and ATI graphics card 501117-001

Before removing the heat sink, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 44).

5. Remove the following components:

a. Hard drive (see

Hard drive on page 50)

b. Optical drive (see

Optical drive on page 46)

c. Keyboard (see

Keyboard on page 60)

d. Switch cover (see

Switch cover on page 65)

e. Display assembly (see

Display assembly on page 68)

f. Top cover (see

Top cover on page 74)

g. Fan (see

Fan on page 79)

Remove the heat sink:

1. Position the computer right-side up, with the front toward you.

Component replacement procedures 81
