TAG 050: Transfer Corona Circuit Shorted
June 1999 Troubleshooting Analysis Guide (TAGs) 3-63
5
Reconnect the transfer corona high voltage unit lead.
• Disconnect J/P23 and J/P41.
• Check P41-37 to P23-3 for continuity.
Is there continuity?
No: Repair or replace the connectors or wiring from P41-37 to P23-3, then turn to TAG 002:
Check & Problem Resolution.
Yes: Continue.
6
Replace the transfer corona.
Has the problem been resolved?
No: Replace the high voltage unit. If this resolves the problem, turn to TAG 002: Check &
Problem Resolution. If the problem has not been resolved, replace the PCL board, then
turn to TAG 002: Check & Problem Resolution.
Yes: Turn to TAG 002: Check & Problem Resolution.
