011 Charge Corona Test
5-10 Diagnostic Tests June 1999
011 Charge Corona Test
1 Remove the photoconductor unit and place it in its protective packaging. Close the top
cover.
2 Go to: 011
3 Press: READY to run the test. The charge corona turns on and off repeatedly.
4 Confirm that the display alternates between “0” and “1,” accompanied each time by a
brief tone. The display indicates the following:
These codes may indicate specific error conditions:
5 Press: STOP to exit.
6 Reinstall the photoconductor unit.
Table 5-7. Charge Corona Test Displays
Display Indication
0 Charge corona off
1 Charge corona on
Table 5-8. Charge Corona Test Error Displays
Display Indication
041 Photoconductor seam sensor short
045 Charge corona short
046 Charge corona open
4-1 You forgot to remove the photoconductor
