107 EIGS/MIGS Bit Map Test (Single Loop)
June 1999 Diagnostic Tests 5-23
107 EIGS/MIGS Bit Map Test (Single Loop)
1 Go to: 107
2 Press: READY to run the test.
3 If no error is detected, the test exits automatically.
4 If an error code appears, look it up in “Error Code/TAG Cross-Reference” on page 2-
3 to determine which TAG to follow.
5 Press: STOP to exit, if an error is reported.
108 EIGS/MIGS Bit Map Test (Continuous Loop)
1 Go to: 108
2 Press: READY to run the test.
3 If no errors are detected:
• The test continues to loop.
• Press STOP to exit.
4 If an error is found:
• The error code displays briefly. If more than one error is detected, the error codes
appear sequentially.
• Look up the codes in the “Error Code/TAG Cross-Reference” on page 2-3 to deter-
mine which TAG to follow.
• Power-on-reset to exit after codes display.
(109 intentionally excluded)
