Lubrication Procedure
General Printer Maintenance 9-11
Front View Lubrication Tables
Duplex Only
Table 9-1. All Printers – Front View Lubrication
Symbol Part Lubricant
H
1 Front roller bearings (paper feed, paper pickup, timing
and exit rollers)
oil
H
2 Vacuum transport drive shaft oil
H
3 Fuser drive bearing oil
H
4 Upper paper guide roller oil
L
5 Fuser drive gear red grease
L
6 Vacuum transport drive gear red grease
L
7 Vacuum transport gear red grease
P
8 Vacuum transport rollers Molycote
Table 9-2. Duplex Front View Lubrication
Symbol Part Lubricant
H
9 Duplex roller bearings oil
P
10 Lower duplex drive assembly Molycote
