Lubrication Procedure
General Printer Maintenance 9-13
Rear View Lubrication Tables
Duplex Only
Table 9-3. All Printers – Rear View Lubrication
Symbol Part Lubricant
H
1 Clutch shafts: upper pick-up roller, lower pick-up roller,
upper feed roller, lower feed roller, paper timing roller
oil
P
2 Upper and lower pick-up roller drive assemblies Molycote
P
3 Main drive gear assembly Molycote
P
4 Main drive gear Molycote
P
5 Main drive motor gear Molycote
P
6 Fuser drive gear Molycote
P
7 Fuser drive assembly Molycote
Table 9-4. Duplex Only Rear Lubrication
Symbol Part Lubricant
H
8 Clutch shaft bearing oil
P
9 Lower duplex drive assembly Molycote
P
10 Upper duplex drive assembly Molycote
P
11 A roller drive gears Molycote
P
12 B roller drive gears Molycote
P
13 C roller drive gears Molycote
