Table 2-2 Left-side components and their descriptions (continued)
Component Description
(3) USB Type-C power connector and port
(continued)
– and –
Connects a display device that has a USB Type-C connector,
providing DisplayPort™ output.
NOTE: Cables and/or adapters (purchased separately) may
be required.
(4) microSD™ memory card reader Reads optional memory cards that enable you to store, manage,
share, or access information.
To insert a card:
1. Hold the card label-side up, with connectors facing
the computer.
2. Insert the card into the memory card reader, and then press
in on the card until it is rmly seated.
To remove a card:
▲ Press in on the card, and then remove it from the memory
card reader.
(5) Power button ● When the computer is o, press the button to turn on
the computer.
● When the computer is on, press the button briey to
initiate Sleep.
● When the computer is in the Sleep state, press the button
briey to exit Sleep (select products only).
IMPORTANT: Pressing and holding down the power button
results in the loss of unsaved information. If the computer has
stopped responding and shutdown procedures are ineective,
press and hold the power button down for at least 5 seconds to
turn o the computer.
(6) Power light On: The computer is on.
O: The computer is o or in the Sleep state.
(7) Magnetic stylus docking Connects an optional stylus.
Left side 5
