Table 3-1 Computer component descriptions and spare part information (continued)
Item Component Spare part number
Equipped with an Intel Celeron N4000 1.1-GHz (turbo up to 2.6-GHz) processor (2400 MHz
FSB, 4-MB L2 cache, dual core, 6 W), a graphics subsystem with UMA memory, 4-GB of
system memory, 64-GB of eMMC storage, and a non-Windows 10 operating system
L70809-001
Equipped with an Intel Celeron N4000 1.1-GHz (turbo up to 2.6-GHz) processor (2400 MHz
FSB, 4-MB L2 cache, dual core, 6 W), a graphics subsystem with UMA memory, 4-GB of
system memory, 32-GB of eMMC storage, and a non-Windows 10 operating system
L70808-001
Thermal Pad Replacement Kit (not illustrated) L76600-001
(5) Speakers (includes left and right speakers, cables, and 2 rubber isolators) L70829-001
(6) Power cable L70822-001
(7a) USB/audio board (includes 2 USB ports and 1 audio combo jack; does not include cable) L70818-001
(7b) USB/audio board high-speed cable L70820-001
(7c) USB/audio board low-speed cable L70821-001
(8) Battery (2-cell, 40.31-Wh, 5.275-Ah, Li-ion, includes cable) L64430-005
(9) Intel 9560 ac 2×2 MU-MIMO + Bluetooth 5.0 M.2 non-vPro CNVi WW with 2 antennas L41693-005
(10) Bottom cover (includes system board shielding and keyboard/top cover magnets) L70816-001
Rubber Foot Kit (not illustrated) L70828-001
Screw Cover Kit (not illustrated) L73740-001
14 Chapter 3 Illustrated parts catalog
