Remove the WLAN module:
1. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.
NOTE: The WLAN antenna cable labeled “1” connects to the WLAN module “Main” terminal
labeled “1”. The WLAN antenna cable labeled “2” connects to the WLAN module “Aux” terminal
labeled “2”.
2. Remove the Phillips PM2.0×2.5 screw (2) that secures the WLAN module to the system board.
(The WLAN module tilts up.)
3. Remove the WLAN module (3) by pulling the module away from the slot at an angle.
NOTE: If the WLAN antenna cables are not connected to the terminals on the WLAN module,
protective sleeves should be installed on the antenna connectors, as shown in the following illustration.
Component replacement procedures
33

HP Chromebook14 Specifications

General

Display Size	14 inches
Operating System	Chrome OS
Wireless	802.11a/b/g/n/ac
RAM	2GB
Storage	16GB eMMC
Display Resolution	1366 x 768
Bluetooth	Bluetooth 4.0
Ports	2 x USB 3.0, 1 x HDMI, 1 x Headphone/Microphone combo jack
Graphics	Intel HD Graphics
