Speakers
Description Spare part number
Speaker Kit (includes left and right speakers and cables) 740154-001
Before removing the speakers, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see
Keyboard/top cover on page 23).
5. Remove the battery (see
Battery on page 28).
Remove the speakers:
1. Disconnect the battery cable from the system board.
2. Disconnect the speaker cable (1) from the system board.
3. Release the speaker cable from the clips (2) built into the base enclosure.
4. Remove the two Phillips PM2.5×4.5 screws (3) that secure the speakers to the base enclosure.
26 Chapter 4 Removal and replacement procedures preliminary requirements
