C7085-90921 Chapter 8 Parts and diagrams 353
Figure 8-16 500-sheet paper feeder
CAUTION Two versions of the HP Color LaserJet 4500 series printers are available. Before ordering parts, you
will need to identify which printer version you are servicing. For more information, see page 329. The
4550 series has some different service parts from the 4500 series.
1
2
Table 8-16 500-sheet paper feeder
Ref. Description Qty. Parts for 4500
series xxG... and
below
Parts for 4500
series xxH... and
above
Parts for 4550
series
1 500-sheet paper feeder 1 C4082-67901 C4082-67901 C4082-67901
2 500-sheet paper cassette 1 RG5-3900-000CN RG5-3900-000CN RG5-3900-000CN
Roller, separation 1 RF5-1885-000CN RF5-1885-000CN RF5-1885-000CN
