HP color laserJet 4550 series - Page 359

C7085-90921 Chapter 8 Parts and diagrams 357
Gear, 26T RS6-0149-000CN RS6-0149-000CN RS6-0149-000CN 8-13 25
Gear, 26T RS6-0159-000CN RS6-0159-000CN RS6-0159-000CN 8-14 28
Gear, 26T/18T RS6-0137-000CN RS6-0137-000CN RS6-0137-000CN 8-14 8
Gear, 27T RS6-0135-000CN RS6-0135-000CN RS6-0135-000CN 8-13 9
Gear, 27T RS6-0135-000CN RS6-0135-000CN RS6-0135-000CN 8-13 10
Gear, 29T RS6-0150-000CN RS6-0150-000CN RS6-0150-000CN 8-13 29
Gear, 29T RS6-0150-000CN RS6-0150-000CN RS6-0150-000CN 8-13 30
Gear, 29T RS6-0152-000CN RS6-0152-000CN RS6-0152-000CN 8-14 17
Gear, 29T/17T RS6-0145-000CN RS6-0145-000CN RS6-0145-000CN 8-13 21
Gear, 30T/16T RS6-0134-000CN RS6-0134-000CN RS6-0134-000CN 8-13 11
Gear, 31T RS6-0136-000CN RS6-0136-000CN RS6-0136-000CN 8-13 13
Gear, 34T/15T RS6-0144-000CN RS6-0144-000CN RS6-0144-000CN 8-13 20
Gear, 35T RS6-0132-000CN RS6-0132-000CN RS6-0132-000CN 8-13 17
Gear, 37T RS6-0143-000CN RS6-0143-000CN RS6-0143-000CN 8-13 26
Gear, 37T/14T RS6-0133-000CN RS6-0133-000CN RS6-0133-000CN 8-13 19
Gear, 39T/31T RS6-0154-000CN RS6-0154-000CN RS6-0154-000CN 8-14 11
Gear, 47T RS6-0147-000CN RS6-0147-000CN RS6-0147-000CN 8-13 15
Gear, 49T RS6-0153-000CN RS6-0153-000CN RS6-0153-000CN 8-14 12
Gear, 52T RS6-0146-000CN RS6-0146-000CN RS6-0146-000CN 8-13 23
Gear, 53T RS6-0155-000CN RS6-0155-000CN RS6-0155-000CN 8-14 10
Gear, 53T/46T RS6-0156-000CN RS6-0156-000CN RS6-0156-000CN 8-13 3
Guide, cable RB2-1277-000CN RB2-1277-000CN RB2-1277-000CN 8-9 3
Guide, cable, lower RB2-1456-000CN RB2-1456-000CN RB2-1456-000CN 8-10 13
Guide, upper drum drawer
cable
RB2-1457-000CN N/A N/A 8-10 1
Handle, ITB drawer RB2-1361-000CN RB2-1361-000CN RB2-1361-000CN 8-8 8
High-voltage power supply RG5-3285-000CN RG5-5165-000CN RG5-5165-000CN 8-8 4
ICL cam assembly RG5-3242-000CN RG5-3242-000CN RG5-3242-000CN 8-14 19
Indicator, paper level RB1-9009-000CN RB1-9009-000CN RB1-9009-000CN 8-17 5
Interconnect PCB RG5-3808-000CN RG5-3808-000CN RG5-3808-000CN 8-5 3
Interconnect PCB RG5-3808-000CN RG5-3808-000CN RG5-3808-000CN 8-9 2
I/O card C4081-60001 C4081-60001 C4207-60001 8-5 8
ITB assembly RG5-5173-000CN RG5-5173-000CN RG5-5173-000CN 8-8 6
ITB cam assembly RG5-3241-000CN RG5-3241-000CN RG5-3241-000CN 8-14 21
ITB drawer assembly RG5-5120-100CN RG5-5120-100CN RG5-5120-100CN 8-8 7
ITB drawer connector VS1-6174-014CN VS1-6174-014CN VS1-6174-014CN 8-12 6
Kit, carousel flap C4084-67909 C4084-67907 C4084-67907 8-11 14
Kit, fuser deflector C4084-67906 C4084-67906 C4084-67906 8-8 12
Kit, imaging drum drawer RG5-5230-000CN N/A N/A Not shown
Laser/scanner assembly RG5-5175-000CN RG5-5175-000CN RG5-5175-000CN 8-10 9
Lever, sensor RB2-0576-000CN RB2-0576-000CN RB2-0576-000CN 8-14 2
Limiter, torque RB1-8974-000CN RB1-8974-000CN RB1-8974-000CN 8-17 3
Link rowel RB2-0614-000CN RB2-0614-000CN RB2-0614-000CN 8-14 25
Metal tab, Tray 2 RB2-0593-000CN RB2-0593-000CN RB2-0593-000CN 8/11 35
Microswitch WC2-5330-000CN WC2-5330-000CN WC2-5330-000CN 8-10 7
Microswitch, ITB WC2-5330-000CN WC2-5330-000CN WC2-5330-000CN 8-12 2
Motor (M1), fusing
assembly
RG5-3227-000CN RG5-3227-000CN RG5-3227-000CN 8-13 24
Motor(M2), pick-up RH7-1343-000CN RH7-1343-000CN RH7-1343-000CN 8-13 14
Paper feed PCB RG5-3810-000CN RG5-3810-000CN RG5-3810-000CN 8-5 5
Paper feed PCB assembly RG5-3810-000CN RG5-3810-000CN RG5-3810-000CN 8-14 18
Paper size sensor PCB RG5-3816-000CN RG5-3816-000CN RG5-3816-000CN 8-5 4
Description Parts for 4500
series xxG... and
below
Parts for 4500
series xxH... and
above
Parts for HP
Color LaserJet
4550 printer
Figure Reference
