C7085-90921 Chapter 8 Parts and diagrams 361
RG5-3292-000CN Sensor (PS13), waste toner 8-8 2
RG5-3296-030CN Drawer switch assembly 8-8 8
RG5-3300-000CN Cover, top 8-5 1
RG5-3309-000CN Carousel brake assembly 8-8 12
RG5-3310-000CN Cover, right front 8-4 3
RG5-3313-000CN Cover, left side 8-4 9
RG5-3319-000CN Drum bushing assembly 8-6 13
RG5-3320-000CN Cover, ITB drawer 8-4 6
RG5-3325-040CN Door, rear access 8-4 11
RG5-3345-000CN Control panel assembly 8-4 5
RG5-3355-000CN Sensor (PS12), toner assembly 8-9 9
RG5-3400-210CN Cassette, 250-sheet 8-15 1
RG5-3781-000CN Cable, main 8-7 4
RG5-3782-000CN Cable, laser 8-8 10
RG5-3783-000CN Cable, developer 8-6 2
RG5-3785-000CN Cable, paper feed 8-11 28
RG5-3786-000CN Cable, ITB 8-10 7
RG5-3787-000CN Cable, fusing/option 8-12 1
RG5-3795-000CN Cable, rotary 8-9 8
RG5-3802-000CN Cable, control panel 8-4 4
RG5-3808-000CN Interconnect PCB 8-3 3
RG5-3808-000CN Interconnect PCB 8-7 2
RG5-3809-000CN DC controller PCB 8-8 3
RG5-3810-000CN Paper feed PCB 8-3 5
RG5-3810-000CN Paper feed PCB assembly 8-12 18
RG5-3811-000CN Developing PCB 8-3 1
RG5-3811-000CN Developing PCB 8-9 5
RG5-3816-000CN Paper size sensor PCB 8-3 4
RG5-3886-000CN Cable, fusing connector 8-9 7
RG5-3887-000CN Cable, fan 8-6 1
RG5-3900-000CN 500-sheet paper cassette 8-16 2
RG5-4055-000CN Duplexing feeder assembly 8-17 2
RG5-4650-000CN Cable, fan 8-8 4
RG5-4651-000CN Cable, ITB switch 8-10 1
RG5-4696-000CN Rowel swing assembly 8-12 23
RG5-5115-000CN Transfer assembly, secondary 8-12 26
RG5-5117-000CN Feeder assembly 8-10 5
RG5-5118-000CN Transfer cam assembly 8-12 7
RG5-5119-000CN Solenoid, Tray 2 feed (SL2) 8-11 8
RG5-5120-100CN ITB drawer assembly 8-6 7
Table 8-19 Numerical parts list
Part number Description Figure Reference
